RM600G Professional Handheld Thermal Camera
RM600G is a professional-grade handheld thermal camera, featuring high resolution and manual focus for temperature measurement.
It is equipped with a self-developed 640×512 infrared detector, providing a high sensitivity of 35mK.
It finds extensive applications in fields such as electric power, electrical automation, building inspection, and commercial HVAC.
| |
| Feature: |
| |
Clear Thermal Images, Precise Temperature Measurement
12μm high-performance 640×512 uncooled infrared detector.
NETD as low as 35mK, capable of distinguishing temperature differences of 0.035°C.
USB plug-and-play analysis, real-time full-frame transmission, and analysis of temperature information.
|
Hard-core Configuration, High-end Experience
IP54 and 2m drop protection, solid and durable.
3.5-inch touch screen, 640×480 resolution
Built-in laser pointer module for quick target locating.
|
Professional Functions, Multi-dimensional Design
Support full-frame high/low-temperature alarms and scheduled image capture, and record temperature rise changes.
Capable of automatically tracking the highest temperature, the lowest temperature, and the central-point temperature within the measurement area.
Support multiple image modes+10 palette settings to meet temperature measurement under different requirements.
Support professional thermal imaging analysis software on the app, PC.
|
.png) |
| |
| |
| |
| |
| |
| |
| |
|
Technical Specifications:
Thermal Imaging
Detector Type: Uncooled infrared detector
Infrared Resolution: 640×512
Pixel Size: 12μm
Spectral Band: 7.5-14μm
NETD: ＜35mK (25°C, F1.0)
Frame Rate: 30 Hz
Lens Focal Length: 9.1mm
FOV: 48°×38°
IFOV: 1.31mrad
Focusing Mode: Manual focusing
Measurement Range: -20°C~+150°C, 100°C~550°C
Measurement Accuracy: ±2°C or ±2% of readings, whichever is greater
Imaging Display
Display: 3.5-inch touch screen, 640×480 resolution
Visible Light Camera: 5 megapixels
Digital Zoom: 1×, 2×, 4×, 8×
Palettes: 10
Image Mode: Infrared, visible light, PIP, dual-spectrum fusion
Temperature Width Stretch: Automatic/Manual
Image Storage
Storage Medium: Standard 32GB MicroSD, up to 512G
Text Notes: Support
Voice Annotation: Support
Image Naming: Auto/manual naming, naming by scanning QR code
Measurement and Analysis
Analysis Functions on the Device: Custom points/lines/areas; up to 10 points, 10 areas, and 10 lines; Center point/Hot and cold spot tracking and temperature display
Supporting Software: PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
System Functions
Communication Protocol: Wi-Fi, USB
Video Transmission: Support UVC video transmission
Laser Pointer: Support
Others
Battery: Rechargeable and detachable lithium-ion battery
Charging Mode: USB Type-C or desktop charger
Battery Life: About 6h (about 3h for a single battery)
Interface: USB Type-C, SD card
Tripod Socket: UNC 1/4-20 interface for tripod
Operating Temperature: -10°C~+50°C
Operating Humidity: 10%~95% (non-condensing)
Storage Temperature: -20°C~+60°C
Ingress Protection Rating: IP54
Shock and Vibration: Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Weight and Dimensions: About 670g, 258.4×105.1×102.3mm
Authentication: CE/RoHS/CMA, etc.
Packing List: Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box |
|
