ABB Electromagnetic flowmeter HygienicMaster FEH610

ABB Electromagnetic flowmeter HygienicMaster FEH610

Product Description


Description

Data



HygienicMaster FEH610 is designed specifically for the food & beverage industries in a cost-effective, robust package.
The sensor is fully CIP/SIP cleanable, manufactured from FDA approved materials and certified with 3A.
Available as an integral or remote mount design – with or without local LCD display. All versions use a common transmitter with easy to understand diagnostic message for improved operator efficiency.
HygienicMaster FEH610´s variable process connections simplify installation and reduce inventory and replacement costs.
HygienicMaster FEH610 is ideally suited for hygienic standard applications.

HygienicMaster FEH610 is ideally suited for hygienic standard applications featuring all functions required - no more and no less.
The perfect device for everyday applications.
Simple and economical.

  • Field-proven powerful and flexible transmitter technology
– ABB common HMI concept
– Easy Set-up function for simple and intuitive configuration
– Through-the-glass operation
  • One single transmitter for all design types
– Integral mount design or remote mount design
– With or without local LCD display
– Universal wide range power supply
– 1 analog output, 2 digital outputs
  • Robust construction for rough environmental conditions
– Hermetically sealed flow sensor
– Protection of the inside components against
      Condensation, vibration and corrosion
      Damages during transport and mounting




General specifications:
  • Measuring value error– 0.5 % of rate
  • Nominal diameter– DN 1 to 100 (1/25 to 4 in.)
  • Process connection– Weld stubs, threaded pipe connections, Tri-clamps, wafer-type, flanges, external threads, flanges in accordance with DIN/EN, ASME, JIS
  • Nominal pressure– PN 10 to 40, ASME CL 150, 300
  • Lining– PFA vacuum stable
  • Protection class– IP 67 or IP 68
  • Fluid temperature– Up to 130 °C (266 °F)
  • Certificates– 3A, FDA approved materials
