TE464G1 Explosion-Proof Gas Imaging PTZ
TE464G1 is a high-performance dual-spectrum gas imaging camera featuring an advanced uncooled infrared detector with a thermal sensitivity of less than 20mK.
It holds dual explosion-proof certifications and has a stainless steel body with an IP68 ingress protection rating.
The device supports multiple protocols, such as Modbus TCP, ONVIF, and GB28181, and supports secondary development.
It can detect Methane (CH4), Sulfur Dioxide (SO2), Freon (R-134a, R-152a) and other gases, and has significant applications in industries such as petroleum extraction and coal processing.
| |
| Feature: |
| |
Highly-Sensitive Uncooled Detector for Non-Contact Gas Imaging Monitoring
The new-generation highly-sensible uncooled detector offers a thermal sensitivity of less than 20mk.
An integrated gas imaging algorithm enables passive, non-contact gas imaging detection, swiftly locating leakage positions.
|
Dual Explosion-Proof Certifications and Stainless Steel Body for Enhanced Safety
Ex d ⅡC T6 Gb/Ex tD A21 IP68 T80℃ dual explosion-proof certifications
304/316L stainless steel body of IP68 ingress protection rating
|
Dual-Spectrum Imaging for 24/7 Monitoring
Combines visible light and thermal imaging for dual-spectrum imaging, catering to both gas imaging and industrial temperature measurement.
Supports professional temperature analysis and intelligent fire point detection, providing continuous 24/7 monitoring services for industrial facilities. |
| |
 |
| |
| |
| |
| |
| |
| |
| |
|
Product Specifications
Thermal
Sensor Type VOx uncooled FPA detector
Spectral Range 7~8.5μm
NETD ≤20mK(@25°C,F#1.0,25Hz)
Max. Resolution 640*512
Pixel Pitch 12μm
Focal Length 25mm
Focus Mode Fixed, motorized focus
FOV 17.5°×14°
F number F1.0
Spatial Resolution 0.480mrad
Color Palettes: 20 modes selectable, such as Blackhot/Whitehot/Rainbow, etc.
Visible
Image sensor 1/1.8inch 4MP CMOS
Max. Resolution 2688×1520
Focal Length 6.5mm~130mm
Focus Mode: Auto/Manual/Semi-auto
FOV 59.6°×35.9°~ 3.2°×1.8°
Defog Support optical defog
PTZ
Pan Range 360° continuous
Pan Speed 0.1°~40°/s
Tilt Range -90°~+90°
Tilt Speed 0.1°~40°/s
Scan Mode Preset/Tour/Scan Patrol/Linear Scan/Pattern
Network
Protocols TCP/IP,UDP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,IGMP,SMTP,NTP,QoS
Interoperability ONVIF/SDK
Simultaneous live view Up to 20 channels
User Management Up to 20 users, 2 levels: Administrator and User
Browser Support IE, Edge, Chrome, Firefox, and other browsers
Video
Max. Resolution
2688×1520 (Visible)
1280×1024 (Thermal)
Image Encoding Format JPEG
Audio Compression G.711A/G.711Mu/PCM/AAC/MPEG2-Layer2
Video Compression H.264/H.265/MJPEG
Main Stream Visible:
50Hz:25fps(2688×1520,1920×1080,1280×720)
60Hz:30fps(2688×1520,1920×1080,1280×720)
Thermal:50Hz:25fps(1280×1024,1280×720,1024×768)
Sub Stream Visible:
50Hz:25fps(1920×1080,1280×720,704×576,352×288)
60Hz:30fps(1920×1080,1280×720,704×480,352×240)
Thermal:50Hz:25fps(640×512,384×288)
Gas Detection
Detection Sensitivity CH4: 5ml/min
Enhanced Recognition Support gas enhancement display mode to improve gas detection sensitivity.
Gas Coloring Support plume coloring
Leak Alarm supports gas leak detection and linked alarms.
Smart Function
Fire Detection Yes
Smart Record Alarm trigger recording, disconnection trigger recording
Smart Alarm supports alarm triggers of network disconnection, IP address conflict, SD card error, illegal access, and burn
VCA Cross-line detection, intrusion detection
Alarm Linkage Recording/Image capture/Sending Email/PTZ linkage/Alarm output
System Interface
Power Supply AC85V~260V
Communication Interface RJ45 self-adaptive 10M/100M Ethernet port
Storage Interface Support Micro SD card (Max. 256G)
RS485 1-channel
General
Operating Conditions -40℃～+60℃; <90%RH
Encapsulation Rating IP68
Power Consumption ≤100W(thermostat activated)
Dimensions(mm) 484.5×303×410mm
Weight 27KG
Explosion-proof Standard Exd IIC T6 Gb/Ex tD A21 IP68 T80℃
|
