RM320 Handheld Thermal Camera
RM320 is equipped with a 12μm infrared detector, which brings 384×288 high-resolution infrared thermal images and a high sensitivity of 35mK to easily capture small hot spots.
With a temperature measurement range extendable to 650°C, the device is suitable for electric routine inspection, electronic circuit design, HVAC, industrial manufacturing, petrochemical industry, photovoltaic testing, and many other fields.
| |
| Feature: |
| |
High-definition Thermal Images, Capturing Subtle Hot Spots
Equipped with a self-developed 384×288 high-pixel 12μm advanced-technology detector.
Capable of distinguishing 0.035°C temperature differences, easily capturing subtle hot spots.
|
Upgraded Performance for More Application Scenarios
-20°C~+650°C wider temperature range, suitable for more industrial temperature measurement scenarios.
IP54 and 2m drop protection, solid and durable.
Standard 32GB Micro SD card, expandable to 512GB, supporting temperature video recording.
|
Smart Upgrade for You to Handle Complexity with Simplicity
Support intelligent shooting, user customization, import and distribution of inspection task packages, simplifying the task process and improving routine inspection efficiency.
Support temperature trend analysis, helping users observe temperature distribution and changes in real time.
Support isotherm function to highlight the temperature segments or areas that need attention.
Support analysis software on the PC client and secondary analysis of video files.
|
 |
| |
| |
| |
| |
| |
| |
| |
|
Technical Specifications:
Thermal Imaging
Detector Type: Uncooled infrared detector
Infrared Resolution: 384×288
Pixel Size: 12μm
Spectral Band: 7.5-14μm
NETD: ＜35mK (25°C, F1.0)
Frame Rate: 30 Hz
Lens Focal Length: 9.1mm
FOV: 27°×20°
IFOV: 1.31mrad
Focusing Mode: Manual focusing
Measurement Range: -20°C~+150°C; 100°C~650°C
Measurement Accuracy: ±2°C or ±2% of readings, whichever is greater
Imaging Display
Display: 3.5-inch touch screen, 640×480 resolution
Visible Light Camera: 5 megapixels
Digital Zoom: 1×, 2×, 4×, 8×
Palettes: 10
Image Mode: Infrared, visible light, PIP, dual-spectrum fusion
Temperature Width Stretch: Automatic/Manual
Image Storage
Storage Medium: Standard 32GB MicroSD, up to 512G
Text Notes: Support
Voice Annotation: Support
Measurement and Analysis
Analysis Functions on the Device: Custom points/lines/areas; up to 10 points, 10 areas, and 10 lines; Center point/Hot and cold spot tracking and temperature display
Supporting Software: PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
Video Functions
Radiation Infrared Video Recording: Support
Non-radiation Infrared or Visible Light Video Recording: Support
System Functions
Intelligent Routine Inspection: Support
Communication Protocol: Wi-Fi, USB
Video Transmission: Support UVC video transmission
Laser Pointer: Support
Others
Battery: Rechargeable and detachable lithium-ion battery
Charging Mode: USB Type-C or desktop charger
Battery Life: About 6h (about 3h for a single battery)
Interface: USB Type-C, SD card
Tripod Socket: UNC 1/4-20 interface for tripod
Operating Temperature: -10°C~+50°C
Operating Humidity: 10%~95% (non-condensing)
Storage Temperature: -20°C~+60°C
Ingress Protection Rating: IP54
Shock and Vibration: Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Weight and Dimensions: About 683.5g, 258.4×105.1×102.3mm
Authentication: CE/RoHS/CMA, etc
Packing List: Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box |
|
